Details
The ultimate weekday commuter & weekend ripper.
top speed: +56 mph
drivers license: M1 (USA)**
weight: 146 lbs + 37 lbs battery
power: 10kW (13,5 hp)
range: 53.5 miles mixed city riding (WMTC-II)*
street legal: Yes
The Kalk INK& is engineered for the outback and for your daily commute. The Kalk INK& is based on the same technology as the Kalk&. It is slightly heavier with a simplified and yet sturdier suspension.
The focus on developing the Kalk models has been off-road performance and innovation.
As there wasn’t anything off-the-shelf to support the new category of Light Electric Off-Road Motorbikes (L.E.Os), every single component had to be developed from an empty sheet, to support the intended level of quality and durability:
Everything from the rims, hubs, stems to the custom Öhlins suspension is engineered and dimensioned, specific for the Kalk and the new category; lightweight electric motorbikes. The light and snappy ride, with its focus on off and on-trail riding, in the outback, means that its main character is about torque and acceleration while providing a quiet gliding and surfy experience. Thanks to its digital pre-setting, serving for 3 different riding modes, it will let anyone fly at their own level.
Please note that Kalk INK& is certified for street use and has great off-road performance as well. A1/ M1 license is required (EU/ USA).
The Kalk INK& is based on the same technology as the Kalk&. This electric motorbike is engineered for both the outback and for your daily commute.
The focus on developing the Kalk models has been off-road performance and innovation.
As there wasn’t anything off-the-shelf to support the category, every single component had to be developed from an empty sheet, to support the intended level of quality and durability:
The sizing, the geometry and engineering of axles, hubs, rims, the cockpit and suspension, as well as building and customizing the different parts of the drivetrain, together with developing a whole new chassis; having led to numerous patent-pending, constitutes the introduction of a new category, the Light Electric Off-Road Motorbikes (L.E.Os). Please note that Kalk INK& is certified for street use and has great off-road performance as well. A1/ M1 license is required (EU/ USA).
53.5 miles mixed city riding (WMTC-II)*
"High speed riding (44mph): 22 miles (WMTC-II)*
* The actual range depends on a number of different aspects, e.g. riding style, rider weight, weather conditions, temperature, road surface and tire pressure.
charging
Type: External charger from standard 110 V/220 V outlets
0-80%: 2 hours
0-100%: 3 hours
battery specs
Cells: premium 18650 lithium cells
Voltage (nominal): 51.8 V
Capacity: 50 Ah / 2.6 kWh
Features: Removable, can be charged when installed in bike or separately
Built in SoC indicator
- explore: The ultimate mode during exploration. It has a limited top speed to 45 km/h (28mph) with a 3-4 hrs battery range.
- excite: Enduro or active trail riding. 1-2 h riding time. With a top speed of 70km/h and good acceleration, this mode is perfect for enduro riding out in the woods.
- excel: Maximal torque and speed, with no restrictions when it comes to performance. This mode is perfect when you need all power available. Riding time up to 1 h.
drivetrain specs
Type: Direct drive, chain
Electric motor: Interior permanent magnet motor
Power: 10 kW (13,5 hp)
Torque (motor axle): 42 Nm
Torque (wheel): 252 Nm
Front sprocket: 12 teeth
Rear sprocket: 72 teeth
Chain/Belt: 420 chain with O-ring
brake specs
Type: Formula motorcycle disc brakes, four pistons callipers. Hand lever for front brake, foot pedal for rear brake.
Disc: Stainless steel, 220 mm diameter, 3.2 mm thickness
brake modes
1) Freewheel: No motor brakes. Gives the same sensation as riding a bike, perfect for mellow riding and the ultimate freedom experience.
2) 2-stroke motor brake with energy regeneration. Moderate engine brake. As you release the throttle you feel the bike slowing down at a slow pace.
3) 4-stroke motor brake with energy regeneration. When releasing the throttle, the bike will slow down significantly. This brake mode is best suited for technical tracks where full control for the bike is needed.
front suspension
Upside down MX spring forks with rebound adjustment, specially engineered for kalk INK.
Travel: 200mm
rear suspension
Type: Direct mounted shock for simplicity and robustness.
wheels and tires
Hubs: Forged and CNC aluminium CAKE hubs with 25 mm axle
Rims: 19"x1.85” custom designed 7116-T6 aluminium motorcycle rims
Tires: 19"x3.00" dual sport motorcycle tires
frame
Build: 6061 aluminium - extruded, forged and CNC machined
fenders and bodywork
PC/ABS plastic
handlebar
Material: Aerospace grade 7050 aluminum
Interface: 31.8 mm
Width: 800 mm
Rise: 20 mm
dashboard
Features: TFT display with battery SoC, speedometer, odometer, trip meter, ride mode selection, brake mode selection and telltales.
dimensions
Wheel base: 1310mm - 51.5''
Seat height: 910mm - 35.75''
Ground clearance: 300mm - 11.75''
Fork angle: 25°
Trail: 87.4mm - 3.5''
Offset: 22mm in triple clamps, 36mm in forks 7/8'' and 1 3/8''
regulatory
Classification: L3e-A1E (EU / Motorcycle (USA)**
License requirement: A1 (EU) / M1 (USA)**
*** Country regulations vary. Your bike will arrive with parts that are compliant with your countries regulations. Please make sure to follow your state’s regulations for local definitions and classifications.
*Note that all details are subject to changes.
** lights are subject to change based on local regulations around the world.
Videos
The street legal Kalk& and Kalk Ink&, Freeride Series, for work & exploring
This clip speaks about the street certified freeride models Kalk & and Kalk Ink&, combining the perfect commuter vessel with back country free time fun.
Part Numbers
| MPN | Store SKU |
|---|---|
| CAK21956646T | CAK21956646T |
